Body material: Aluminium
Filling: Epoxy+Quartz
Lens Material: PMMA
Colors: White, Red, Yellow, Green, Blue
Size: 100*100*20+50mm
Reflective road studs provide most effective night guidance even under the most adverse weather conditions. Aluminium reflective road studs are available in different sizes to delineate both the carriage way at the center and at the edges of roads. These are available in aluminum as well as in rigid ABS plastic. The special material composition enables the studs to bear severe impacts.
Aluminium reflective road studs are one of raised pavement markers. Aluminium reflective studs on motorway is used for dividing the road boundary,for safety,reducing the accidents,made from aluminium alloy attached with the reflective sheet made from the acrylic plastic sheet.This acrylic is a reflective prism glass style and available 1 or 2 sides on road stud. In addition,there will be thin layer of the coated glass in order to enhance the reflective index during night time.
The specifications of Aluminium reflective road studs:
| Model No. | NK-1004 |
| Color | Red, Yellow, Green, Blue, White |
| Lens Material | PMMA |
| Body Material | Aluminium |
| Filling | Epoxy+ Quartz Sand |
| Size | 100*100*20+50mm |
| Temperature | -40~60°C |
| Load capacity | 5 T |
| Packing | 50 pcs / ctn |
| Life span | >3 years |
| Certificates | ASTM & EN1463-1 |
Whats the different color aluminium reflective road studs mean on the motorway?
Red studs- mark the left edge of the road.
White studs- mark the lanes or the middle of the road.
Amber studs- mark the central reservation of a dual carriageway or motorway.
Green studs- mark the edge of the main carriageway at lay-bys and slip roads
